Wolf 12k Burner Assembly - 809705
Genuine Wolf sealed surface burner with spark ignitor included
Every order is manually reviewed by our parts experts before processing. If you provide your model or serial number and we ship the wrong part, we’ll cover the return or exchange, including a prepaid return label.
OEM part description
Genuine Wolf 12,000 BTU sealed surface burner assembly 809705 used in select Wolf gas cooktops. This includes the spark ignitor, providing the burner and ignition electrode together as one service component.
Part details
The burner assembly distributes the gas-and-air mixture through the burner ports while the ignitor provides the spark required for ignition. Heat damage, corrosion, blocked burner openings, or deterioration around the electrode can contribute to uneven flame, delayed ignition, repeated clicking, or failure to light.
Part Specifications:
Part Type: Sealed surface burner assembly
Burner Output: 12,000 BTU
Burner Size: Medium
Includes: Spark ignitor
Burner Cap: Separate component
Quantity: 1 burner assembly
Brand: Genuine Wolf
